Beam  5" x 96" Pallet Rack

Jaken Beam 5" x 96" Pallet Rack 215-MB50096

215-MB50096 Jaken step/load pallet rack beam designed for heavy-duty warehouse racking and industrial shelving applications; 5" face x 96" clear span, steel construction and boltless teardrop/step-load compatibility for fast, tool-free installation.

Features & Benefits

Heavy-gauge steel construction with industry-standard powder-coat finish (commonly shown in orange) resists corrosion and wear. Step/load (rivet) profile provides secure seating into teardrop uprights and accepts 3-pin connectors for reliable engagement. Integrated safety locks/clips at each end prevent accidental dislodging. Two beams form a single shelf level; compatible with wire decking, pallet supports and seismic plates for adaptable warehouse storage.

Specifications

Product ID: 215-MB50096 (also listed as JK-215-MB50096). Dimensions: 5" face x 96" clear span. Typical single-beam weight reported ~28.4 lbs; common rated capacities for a pair of 5" Jaken step/load beams fall in the ~6,810–7,035 lb range (capacities specified per pair, based on evenly distributed load). Uses 3-pin connectors for 5" beams; boltless assembly with replaceable safety clip. Finish: powder-coated steel.

Applications

Ideal for warehouse racking, heavy-duty shelving, industrial storage, retail stockrooms, shipping/receiving and MRO backrooms. Suitable where durable steel storage racks, boltless shelving and high-capacity load-bearing shelves are required.
